CHINA G209 BOW SCREW PIN SHACKLE - G210

More info

G209 Bow Screw Pin Shackle (G210 Type)

The G209 Series Bow Shackles are heavy-duty connecting links used in rigging, lifting, and tie-down systems. Featuring a distinct "bow" or "anchor" shape, these shackles allow for side loading and multi-directional pulling, making them more versatile than standard D-shackles. Equipped with a threaded screw pin, they are designed for quick attachment and removal, primarily in applications where the shackle is used for temporary or non-permanent connections.

Product Specifications

Model: G209 / G210 Style
Type: Bow Shackle with Screw Pin
Material: Forged Carbon Steel with Alloy Pin
Finish: Hot Dipped Galvanized (Body) and Powder Coated / Galvanized (Pin)
Safety Factor: 4:1 (Minimum Breaking Strength is 4 times the WLL)
Application: Marine rigging, construction lifting, off-road recovery, and industrial towing

Key Features

Multi-Directional Loading: The wide bow shape allows for multiple sling legs to be attached to a single shackle without crowding or compromising the structural integrity.
Forged for Safety: Quenched and tempered forged steel provides high strength and helps ensure the shackle will deform rather than shatter if overloaded.
Galvanized Protection: The zinc-coated finish offers superior resistance to rust and oxidation, particularly in salt-water or high-moisture environments.
Secure Screw Pin: The threaded pin allows for rapid installation. Note: For permanent installations or applications involving vibration, safety bolt shackles are recommended.
Standardized Sizing: Manufactured to meet G209 industrial specifications, ensuring compatibility with standard hooks, eyes, and chains.
